| Luogo di origine: | Cina |
|---|---|
| Marca: | Custom OEM |
| Certificazione: | ISO 9001:2015, CE, RoHS, IP54 |
| Numero di modello: | SP-GS-E003 |
| Quantità di ordine minimo: | 100 pezzi |
| Prezzo: | USD 2.00-50.00 per Piece |
| Imballaggi particolari: | Schiuma + cartone + pallet di legno; Disponibili inserti in schiuma personalizzati |
| Tempi di consegna: | 10-20 giorni lavorativi |
| Termini di pagamento: | T/T,L/C,PayPal |
| Capacità di alimentazione: | 100.000 pezzi al mese |
| Materiale: | Acciaio zincato SGCC / DC01 / DX51D / SECC / zincato a caldo | Spessore del materiale: | 0.5mm - 3.0mm |
|---|---|---|---|
| Tolleranza: | ±0,1 mm | Processo: | Tranciatura, Stampaggio, Piegatura, Saldatura, Rivettatura, Assemblaggio |
| Metodi di saldatura: | Saldatura a punti, saldatura MIG a CO2, saldatura TIG, saldatura perni | Trattamento superficiale: | Verniciatura a polvere, verniciatura a liquido, serigrafia, zincatura (così com'è), rivestimento |
| Grado di protezione: | IP54/IP65/IP66 Disponibili | tonnellaggio della stampa: | 63T - 250T |
| Dimensione massima della custodia: | 2000 mm x 1200 mm x 800 mm | Applicazione: | Armadi di controllo elettrici, alloggiamenti per apparecchiature industriali, custodie per telecomun |
| Controllo qualità: | CMM, misuratore di spessore del rivestimento, camera in nebbia salina, test di ingresso d'acqua | Formato del disegno: | PASSO, IGES, DWG, DXF, PDF, SolidWorks |
| Evidenziare: | Galvanized Steel Stamping Enclosure,Sheet Metal Welding Housing,Custom Electrical Cabinet OEM |
||
This custom galvanized steel sheet metal stamping enclosure housing is designed and manufactured for electrical cabinets, industrial control boxes, and outdoor equipment protection applications requiring structural durability, corrosion resistance, and cost-effective production scalability. Fabricated from SGCC hot-dip galvanized steel sheet with zinc coating weights of Z120-Z275 g/m², these enclosures combine the protective benefits of galvanized corrosion resistance with the forming flexibility of precision stamping and CNC bending. The complete manufacturing workflow integrates blanking, stamping, CNC bending, spot welding, MIG welding, threaded fastener insertion, and final surface finishing into a seamless production line capable of delivering 100,000+ units per month. Our facility operates 20+ mechanical presses from 63T to 250T capacity alongside CNC press brakes, robotic welding stations, and an automated powder coating line with pretreatment, drying, and curing stages. With 15+ years of sheet metal fabrication experience serving international industrial equipment OEMs, we provide complete enclosure solutions from engineering design review and prototyping through series production with consistent quality and on-time delivery performance.
Key Features| Parameter | Specification |
|---|---|
| Material | Galvanized Steel SGCC / DC01 / DX51D / SECC / DX53D |
| Zinc Coating Weight | Z120 (120 g/m²) to Z275 (275 g/m²) |
| Material Thickness | 0.50mm - 3.00mm |
| Dimensional Tolerance | ±0.10mm |
| Bend Angle Accuracy | ±0.5° |
| Max Enclosure Dimensions | 2000mm (L) x 1200mm (W) x 800mm (H) |
| Press Tonnage Range | 63T - 250T |
| Welding Methods | Spot Welding, CO2 MIG Welding, TIG Welding, Stud Welding |
| Surface Finishing | Powder Coating 60-120μm, Liquid Painting, E-Coating, Galvanized (Natural) |
| Protection Rating | IP54 Standard, IP65/IP66 with Gasket Sealing |
| Powder Coating Colors | RAL 7035 (Light Gray), RAL 7032 (Pebble Gray), RAL 9005 (Jet Black), Custom RAL |
| Assembly Hardware | PEM Nuts, Rivet Nuts, Weld Nuts, Weld Studs, Threaded Inserts |
| Accessories Available | Mounting Plate, DIN Rail, Cable Gland Plate, Hinges, Locks, Gaskets, Ventilation Louvers |
| Quality Certification | ISO 9001:2015, CE, RoHS, IP54/IP65/IP66 |
| Drawing Formats Accepted | STEP, IGES, DWG, DXF, PDF, SolidWorks, Inventor |
Galvanized steel stamping and welding enclosures serve diverse industrial, commercial, and infrastructure equipment protection applications. Electrical control cabinets for industrial automation systems, motor control centers, and power distribution panels require robust mechanical protection for sensitive electrical components while providing convenient access for maintenance and configuration. Outdoor telecom equipment enclosures for 5G base station power supplies, fiber optic termination boxes, and radio remote unit housings demand weather-resistant construction with IP65 or IP66 ingress protection ratings and UV-stable powder coating for long-term outdoor deployment. Industrial equipment housings for CNC machine controls, hydraulic power pack enclosures, air compressor covers, and pump station shelters benefit from the structural rigidity of welded steel construction combined with the corrosion protection of galvanized substrate and powder coating finish. Junction boxes and terminal enclosures for building electrical systems, solar PV combiner boxes, and EV charging station power modules require compact, cost-effective enclosures with appropriate cable entry configurations and DIN rail mounting provisions. HVAC equipment enclosures for rooftop air handling units, chiller control panels, and boiler system controllers demand weather resistance and thermal management integration including ventilation and fan mounting provisions.
Packaging and Quality AssuranceAll sheet metal stamping enclosures are individually wrapped in protective polyethylene film or foam sheet, placed in double-wall corrugated cartons with custom foam inserts or molded pulp corner protectors, and palletized on fumigated wooden pallets with edge protectors and stretch wrap. Hardware kits including mounting screws, hinges, locks, and gaskets are packed in sealed poly bags and secured inside the enclosure to prevent loss during transit. Each shipment includes dimensional inspection reports, coating thickness measurements, weld quality records, IP rating test certificates where applicable, material certifications, and Certificate of Conformance. Full material traceability from steel coil certification through finished enclosure serial number is maintained for quality-critical applications. Standard production lead time is 10-20 working days for prototypes and small batch orders, with accelerated 7-day express service available for urgent requirements.
